| MXZ4B36NA Outdoor Unit Performance: |
| Rated Cooling Capacity (BTU): |
36000 |
| Cooling Capacity Range (BTU): |
12,600 - 36,400 |
| Cooling Total Input (W): |
3,940 |
| Rated Heating Capacity (BTU): |
36,000 |
| Heating Capacity Range (BTU): |
11,400 - 43,000 |
| Heating Total Input (W): |
3,100 |
| MXZ4B36NA Outdoor Unit Power: |
| Power Supply: |
1-phase, 60Hz, 208 / 230V *2 |
| Voltage Indoor - Outdoor S1 - S2: |
AC 208 / 230V |
| Voltage Indoor - Outdoor S2 - S3: |
DC12-24V |
| MXZ4B36NA Outdoor Unit Specifications: |
| MCA (A): |
19 |
| MOCP (A): |
20 |
| Fan Motor (FLA): |
0.93 |
| MXZ4B36NA Outdoor Unit Specifications: |
| Compressor Type: |
DC Inverter-driven Twin Rotary |
| Compressor RLA: |
14.4 |
| Compressor LRA: |
15 |
| Airflow Cooling/Heating (CFM): |
2,068/2,068 |
| Refrigerant Control: |
Linear Expansion Valve |
| Defrost Method: |
Reverse Cycle |
| Cooling Sound Pressure (dB): |
54 |
| Heating Sound Pressure (dB): |
57 |
| External Finish Color: |
Munsell No. 3.0Y 7.8 / 1.1 |
| MXZ4B36NA Outdoor Unit Dimensions: |
| Width (Inches): |
35-7/16 |
| Depth (Inches): |
12-5/8 |
| Height (Inches): |
35-7/16 |
| Weight (lbs): |
153 |
| Number of Indoor Units: |
2, 3, 4 |
| MXZ4B36NA Refrigerant Specifications: |
| Refrigerant Type: |
R410A |
| Refrigerant Charge (Lbs, Oz): |
8, 13 |
| MXZ4B36NA Outdoor Unit Connections: |
| Gas Side O.D. (Inches): |
A: 1/2, B,C,D:3/8 |
| Liquid Side O.D. (Inches): |
1/4 |
| Max Height Difference (Feet): |
49 |
| Max Total Length (Feet): |
230 |
| SEZKD15NA4 Indoor Unit Performance: |
| Rated Cooling Capacity (BTU): |
15000 |
| Rated Heating Capacity (BTU): |
18,000 |
| SEZKD15NA4 Indoor Unit Power: |
| Power Supply: |
1-phase, 60Hz, 208 / 230V *2 |
| Voltage Indoor - Outdoor S1 - S2: |
AC 208 / 230V |
| Voltage Indoor - Outdoor S2 - S3: |
DC24V |
| SEZKD15NA4 Indoor Unit Specifications: |
| MCA (A): |
1.0 |
| Airflow Lo-Med-Hi (CFM): |
353-441-529 |
| External Static Pressure (In. W.G.): |
0.02-0.06-0.14-.020 |
| Sound Pressure Levels Lo-Med-Hi (dB): |
30-34-37 |
| External Finish Color: |
Galvanized-steel Sheets |
| SEZKD15NA4 Indoor Unit Dimensions: |
| Width (Inches): |
39 |
| Depth (Inches): |
27-9/16 |
| Height (Inches): |
7-7/8 |
| Weight (lbs): |
51 |
| Drain Lift Mechanism Height (Inches): |
21-11/16 |
| Field Drainpipe Size O.D. (Inches): |
1-1/4 |
| Remote Control Type (NOT Included): |
Wired |
| SEZKD15NA4 Indoor Unit Connections: |
| Gas Side O.D. (Inches): |
1/2 |
| Liquid Side O.D. (Inches): |
1/4 |
| SEZKD18NA4 Indoor Unit Performance: |
| Rated Cooling Capacity (BTU): |
18000 |
| Rated Heating Capacity (BTU): |
20,100 |
| SEZKD18NA4 Indoor Unit Power: |
| Power Supply: |
1-phase, 60Hz, 208 / 230V *2 |
| Voltage Indoor - Outdoor S1 - S2: |
AC 208 / 230V |
| Voltage Indoor - Outdoor S2 - S3: |
DC24V |
| SEZKD18NA4 Indoor Unit Specifications: |
| MCA (A): |
1.0 |
| Airflow Lo-Med-Hi (CFM): |
423-529-635 |
| External Static Pressure (In. W.G.): |
0.02-0.06-0.14-.020 |
| Sound Pressure Levels Lo-Med-Hi (dB): |
30-34-38 |
| External Finish Color: |
Galvanized-steel Sheets |
| SEZKD18NA4 Indoor Unit Dimensions: |
| Width (Inches): |
46-7/8 |
| Depth (Inches): |
27-9/16 |
| Height (Inches): |
7-7/8 |
| Weight (lbs): |
60 |
| Drain Lift Mechanism Height (Inches): |
21-11/16 |
| Field Drainpipe Size O.D. (Inches): |
1-1/4 |
| Remote Control Type (NOT Included): |
Wired |
| SEZKD18NA4 Indoor Unit Connections: |
| Gas Side O.D. (Inches): |
1/2 |
| Liquid Side O.D. (Inches): |
1/4 |
| Mitsubishi Warranty: |
| Compressor: |
7 Years |
| Parts: |
5 Years |
