Processing. Please wait. Brand: Daikin Save Listing| Email Listing | Share Product Name: RXYQ168PBYD Daikin VRV Outdoor Unit 14 TON 430V cool and heat air conditioner condensing unit prevnext prevnext Item#: RXYQ168PBYD Your Price: Email For Price Click Here Choose QTY: 1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Required Product Details Manuals Video Warranty Shipping Info Returns / Policy Ask A Question Product Details - RXYQ168PBYD Inverter Heat Pump units allow for either cooling or heating from one system Up to 62 indoor units can be operated from a single outdoor unit using a variable-speed compressor system with 48 capacity steps Continuous operation 0°F DB (-4°F WB) – 77°F DB (60°F WB) in heating mode and 23°F DB – 122°F DB in cooling mode Daikin’s optimized scroll compressor designed for R-410A provides a quiet, reliable energy-efficient operation Daikin’s management and oil-equalizing technology assures maximum reliability and flexibility to the VRV system with piping lengths of up to 540ft., for a total networked length of up to 3,280 ft. of liquid line. Anticorrosion treatment standard on exterior metal parts and heat exchanger Fully compatible with the complete Daikin control suite including the Intelligent Touch controller, the Intelligent Touch Manager, and the LonWorks® and BACnet® gateways Daikin’s constant efforts have been devoted towards using the latest and most revolutionary technologies in the development of the VRV system for large-sized buildings. The system offers larger outdoor capacities, greater energy savings, easier installation, longer actual and total piping, and more. Fans and grilles Heat exchanger High efficiency compressor Heat transfer circuit Compact electrical panel Smooth sine wave DC Inverter DC fan motor 1. Newly improved fans and grilles A higher external static pressure has been achieved-from 0.24” to 0.32” W.G.-thanks to reduced internal pressure loss, use of the new fans and the new grilles. New aero spiral fan and aero asymmetrical fanThe area of these new fan blades has been increased and optimized for each casing. This greatly reduces pressure loss, resulting in a higher external static pressure. New aero spiral fan (Powerful Dual DC fan)In the 12-Ton unit, a single fan with a diameter of 27.5" has been split into two fans with diameters of 21.25" each. Blade area has been increased by 20% to increase airflow. Aero smooth grilleThe three-dimensional, integrated, soft woven steel grilles are covered with a plastic coating that protects them from rotating elements and the possibility of fire damage. 2. Heat exchanger The new heat exchanger contributes to a higher COP because of an increase from 7% to 10% of the effective length as well as an optimized e-Pass heat exchanger. 3. Improving the high efficiency compressor to achieve a higher COP and larger capacity Reluctance DC scroll compressor Daikin's unique scroll compressor minimizes heat loss, and is driven by a high efficiency motor to achieve significant energy savings. * High thrust mechanism:By introducing high pressure oil, the reactive force from the fixed scroll is added to the internal force, thereby reducing thrust losses. This results in improved efficiency and suppressed sound levels. 4. Heat transfer circuit By performing sub cooling before the expansion process, the volume of refrigerant that needs to be circulated to the indoor units can be reduced without lowering the evaporation temperature. This permits the use of narrower piping. 5. Compact Electrical Panel Has a compact casing by stacking the Inverter and control PCBs plus optimizing the internal design to suit airflow speed. This achieves lower noise and reduces the power input. 6. Smooth sine wave DC Inverter By adoption of the Sine Wave, which smoothes the rotation of the motor, operation efficiency is dramatically improved. 7. DC fan motor Across entire range of models (from 6 to 30 Ton). Efficiency improvement by up to 40% especially at low speed. Your Phone Number : Enter Your Phone Number Your Email : Enter Your Email Not valid email address What is your message about : - Select One - - Select One - Sales Questions General Support Technical Support Webmaster Please select your message about What Is The Status Of Your Project? : - Select One - - Select One - Ready To Buy Planning/Budgeting Just Curious/Not Buying Anytime Soon Please select status of your project Type your name and message here : Verification Code : 6 + 6 Send Shop for Daikin and browse manuals and details of RXYQ168PBYD Air Conditioning Company Columbus, OH HVAC Contractors Elkhart, IN Air Conditioner Service Arcadia, CA HVAC Contractors Des Plaines, IL Heating Repair Highland, CA Certified Electrician Arlington, VA Top Watch This Item Your Phone Number: Your Email: Message here: Make an offer Quantity you would like to buy: 1 1 2 3 4 5 6 7 8 9 10 How much would you like to pay for each unit: Type your Message: Shipping Address: URL of the website where you saw cheaper price Or better deal: Your email address: Your phone number: E-mail a friend about this item Your friend email: Your Email: Message here: Email For Price Your Phone Number: Your Email: Shipping Zip Code: How soon do you need this product?: Immidiately Immidiately Within a week Within couple of months Just looking for price Message here:
Brand: Daikin Save Listing| Email Listing | Share Product Name: RXYQ168PBYD Daikin VRV Outdoor Unit 14 TON 430V cool and heat air conditioner condensing unit prevnext prevnext Item#: RXYQ168PBYD Your Price: Email For Price Click Here Choose QTY: 1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Required
Product Details Manuals Video Warranty Shipping Info Returns / Policy Ask A Question Product Details - RXYQ168PBYD Inverter Heat Pump units allow for either cooling or heating from one system Up to 62 indoor units can be operated from a single outdoor unit using a variable-speed compressor system with 48 capacity steps Continuous operation 0°F DB (-4°F WB) – 77°F DB (60°F WB) in heating mode and 23°F DB – 122°F DB in cooling mode Daikin’s optimized scroll compressor designed for R-410A provides a quiet, reliable energy-efficient operation Daikin’s management and oil-equalizing technology assures maximum reliability and flexibility to the VRV system with piping lengths of up to 540ft., for a total networked length of up to 3,280 ft. of liquid line. Anticorrosion treatment standard on exterior metal parts and heat exchanger Fully compatible with the complete Daikin control suite including the Intelligent Touch controller, the Intelligent Touch Manager, and the LonWorks® and BACnet® gateways Daikin’s constant efforts have been devoted towards using the latest and most revolutionary technologies in the development of the VRV system for large-sized buildings. The system offers larger outdoor capacities, greater energy savings, easier installation, longer actual and total piping, and more. Fans and grilles Heat exchanger High efficiency compressor Heat transfer circuit Compact electrical panel Smooth sine wave DC Inverter DC fan motor 1. Newly improved fans and grilles A higher external static pressure has been achieved-from 0.24” to 0.32” W.G.-thanks to reduced internal pressure loss, use of the new fans and the new grilles. New aero spiral fan and aero asymmetrical fanThe area of these new fan blades has been increased and optimized for each casing. This greatly reduces pressure loss, resulting in a higher external static pressure. New aero spiral fan (Powerful Dual DC fan)In the 12-Ton unit, a single fan with a diameter of 27.5" has been split into two fans with diameters of 21.25" each. Blade area has been increased by 20% to increase airflow. Aero smooth grilleThe three-dimensional, integrated, soft woven steel grilles are covered with a plastic coating that protects them from rotating elements and the possibility of fire damage. 2. Heat exchanger The new heat exchanger contributes to a higher COP because of an increase from 7% to 10% of the effective length as well as an optimized e-Pass heat exchanger. 3. Improving the high efficiency compressor to achieve a higher COP and larger capacity Reluctance DC scroll compressor Daikin's unique scroll compressor minimizes heat loss, and is driven by a high efficiency motor to achieve significant energy savings. * High thrust mechanism:By introducing high pressure oil, the reactive force from the fixed scroll is added to the internal force, thereby reducing thrust losses. This results in improved efficiency and suppressed sound levels. 4. Heat transfer circuit By performing sub cooling before the expansion process, the volume of refrigerant that needs to be circulated to the indoor units can be reduced without lowering the evaporation temperature. This permits the use of narrower piping. 5. Compact Electrical Panel Has a compact casing by stacking the Inverter and control PCBs plus optimizing the internal design to suit airflow speed. This achieves lower noise and reduces the power input. 6. Smooth sine wave DC Inverter By adoption of the Sine Wave, which smoothes the rotation of the motor, operation efficiency is dramatically improved. 7. DC fan motor Across entire range of models (from 6 to 30 Ton). Efficiency improvement by up to 40% especially at low speed. Your Phone Number : Enter Your Phone Number Your Email : Enter Your Email Not valid email address What is your message about : - Select One - - Select One - Sales Questions General Support Technical Support Webmaster Please select your message about What Is The Status Of Your Project? : - Select One - - Select One - Ready To Buy Planning/Budgeting Just Curious/Not Buying Anytime Soon Please select status of your project Type your name and message here : Verification Code : 6 + 6 Send Shop for Daikin and browse manuals and details of RXYQ168PBYD Air Conditioning Company Columbus, OH HVAC Contractors Elkhart, IN Air Conditioner Service Arcadia, CA HVAC Contractors Des Plaines, IL Heating Repair Highland, CA Certified Electrician Arlington, VA Top
