INDOOR UNIT FEATURES
• Ducted air handler provides a solution to cool and heat larger zones
• Highly efficient completely enclosed EC motor
• Selectable external static pressure: 0.30, 0.50 and 0.80 in.WG with 3 fan speeds at each static setting
• 1 inch R4.2 fiberglass free insulation reduces condensation and increases efficiency
• Positive pressure cabinet with air leakage of less than 2.0% at 1.0 in. w.g. (Tested per ASHRAE Standard 193)
• Unique blow through design allows simple coil cleaning when the blower is removed
• Multi-position installation: horizontal (left or right), vertical (upflow) • Optional electric heat kit for additional heating capacity
• Optional humidifier control, ERV control and auxiliary heat control
• Optional downflow kit
MHK2 Thermostat NOT INCLUDED.
OUTDOOR UNIT FEATURES
• Variable speed INVERTER-driven compressor
• Innovative Joint Lap DC Motor leads to high efficiency and reliability
• Pulse Amplitude Modulation technology
• High-performance grooved piping for increased heat exchange efficiency
