Brand: TradePro Save Listing| Email Listing | Share Product Name: Evaporator Motor TradePro TP-E75-MHP2 1/5-3/4 HP 208/230 Multiple Horsepower RESCUE DIRECT DRIVE Item#: TradePro TP-E75-MHP2 Reg Price: $348.53 Your Price: $176.30 Choose QTY: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Required
Product Details Manuals Video Warranty Shipping Info Returns / Policy Ask A Question Product Details - TradePro TP-E75-MHP2 Weight 21.35 Pound (lb.) Width 5.625 Inches (in) Height 5.625 Inches (in) Country of Origin MEX UPC or Barcode 00816075029873 Hazardous Material No EPA Cert Required No Length 7.152 Inches (in) Brand TradePro Voltage 208-230 VAC Full Load Amps 3.8 Amps 3.8 Phase Single Cycle/Hertz 60 Capacitor MFD µF 20/370 RPM 1075 Rotation Counter-Clockwise Insulation Class B Motor HP 3/4 HP Motor Type PSC Shaft Diameter 1/2" Shaft Length 5 Bearing Type Ball Enclosure OAO Lead Length 36 NEMA Frame 48Y Number of Bearings 2 Number of Poles 6 Number of Speeds 4 Poles Six Protection Auto Service Factor 1 Type Evaporator Fan Warranty Offered 1 Year UL Listed No UL Recognized Yes Thermal Protection Yes Description Universal multi horse power fractional evaporator motor. 208-230V single phase, 8.1 amp draw. Speeds-800, 950, 1075. Side shell mount, pre-drilled to accept Rheem mount wings, resilient mount rings. 48 frame, 5" keyed shaft, 1/2" diameter, Ball bearing, reversible direction. 20mf 370 or 440V capacitor. Please Note! The actual brand name on product received may vary from the description but will always be manufactured to the same strict standard of quality. Cross-Reference The main item on this page is a comparable or direct substitute for any of the products below. By purchasing the comparable or substitute product, there may be special installation considerations and it may or may not be covered under the original products warranty. Brand Model DiversiTech WG840467 Fasco D2833 GE Motors 3467 Genteq 3467 Johnstone S89-288 Regal Beloit FD6001 TopTech TT-E75-MHP2 U.S. Motors 5471 Your Phone Number : Enter Your Phone Number Your Email : Enter Your Email Not valid email address What is your message about : - Select One - Sales Questions General Support Technical Support Webmaster Please select your message about What Is The Status Of Your Project? : - Select One - Ready To Buy Planning/Budgeting Just Curious/Not Buying Anytime Soon Please select status of your project Type your name and message here : Verification Code : 3 + 3 Send Shop for TradePro and browse manuals and details of TradePro TP-E75-MHP2 AC Repair New Berlin, WI HVAC Contractors Columbia, SC Duct Cleaning New Braunfels, TX HVAC Contractors New Haven, CT Home AC Repair Manchester, NH Certified Electrician Boston, MA Top
Universal multi horse power fractional evaporator motor. 208-230V single phase, 8.1 amp draw. Speeds-800, 950, 1075. Side shell mount, pre-drilled to accept Rheem mount wings, resilient mount rings. 48 frame, 5" keyed shaft, 1/2" diameter, Ball bearing, reversible direction. 20mf 370 or 440V capacitor. Please Note! The actual brand name on product received may vary from the description but will always be manufactured to the same strict standard of quality.
The main item on this page is a comparable or direct substitute for any of the products below. By purchasing the comparable or substitute product, there may be special installation considerations and it may or may not be covered under the original products warranty. Brand Model DiversiTech WG840467 Fasco D2833 GE Motors 3467 Genteq 3467 Johnstone S89-288 Regal Beloit FD6001 TopTech TT-E75-MHP2 U.S. Motors 5471
