CEILING CASSETTE

DUCTLESS MINI SPLIT AIR CONDITIONER HEAT PUMP

208-230V 16 SEER

Function

•        Cooling
•     Heating
•     Dehumidification
•     Air Purification

 Description

• Single Zone Air Conditioner with Heat Pump
• 30000 BTU 2 Ton Capacity Heating Cooling And Dehumidification
• 16 SEER DC Inverter Compressor
• Super Quite Auto Restart, digital Timer

 FEATURES

·      208-230/1/60 power input

·      Quiet and efficient heating & cooling.

·      LED display shows set temperature & operating modes.

·      4-way discharge fan.

·      U-TOUCH

·      Remote Control.

·      DC Inverter technology

·      Wide working ambient temperature ranges

·      Stylish design

·      Compact outdoor unit with side discharge

·      Outdoor unit ships pre-charged.

·      World-class quality compressors

·      Durable powder coated cabinet

·      Default flare brass connection valves

·      Knock-outs for refrigerant pipes and wires

·      Built to ETL/UL/CSA/ARI standards

·      Easy installation and maintenance

  YMGI Smart Technologies

• Auto-Restart: After a power cut the unit will restart automatically with the previous function setting when the power returns.
•  Intelligent Auto-Defrosting: The unit can enter or quit the defrosting mode automatically by timely detecting the frosting situation of the outdoor unit.
•  Sleep Mode: Because our body temperature cools down as we sleep, the unit automatically adjusts the setting for all-night comfort.
•  Air Purifying and Deodorizing Filters: Industrial development has offered from one side a better life style, but on the other side, it has increased polluting substances presence in the air that helps in spreading of various kinds of diseases. Among the polluting agents, the ones we can more frequently find at home are anti-bacterial dust particles, moulds and etc, which are causing allergic phenomenon, breathing and typical upper respiratory problems. This dual washable filter screen is effective in preventing anti-bacteria mould and duct particles and ensuring a healthy indoor environment.
• Turbo Mode: This function enables the unit to reach the preset temperature in the shortest time.
•  Self-diagnosis and Auto-Protection Function: This function can electronically detect the errors and display the diagnosis by a series of flashing LEDs on the indoor unit. Then the unit will automatically switch to protection mode.

IMPORTANT NOTES ABOUT THE DC INVERTER SYSTEM VARIOUS PERFORMANCES:

• The rated performance data printed on the nameplate were tested per AHRI 210/240 standards at standard indoor & outdoor conditions and standard installation set-up.
•  Actually the DC inverter outdoor unit could modulate to match whatever capacity needs are called/requested from indoor side, to produce a wide range of capacities, minimum could be about 15% of the rated number and maximum could be around 160% of the rated number.
•  Once the DC inverter system is installed, each indoor unit's output and so the outdoor unit performance will all vary over the operation period: soft starting, turbo quick cooling/heating, maintaining, defrosting, switching, and other condition changes.
•  Actual performance varies upon many factors such as indoor and outdoor temperatures, inter-connecting pipe length/ bending, elevation difference between indoor and outdoor units, refrigerant charging level, vacuum level, leakage, air or moisture or contamination level, foreign substance left in the piping, indoor filter clean level, indoor and outdoor coil conditions, and other factors.
• When the rated total capacity of all the indoor units exceeds the rated capacity of outdoor unit, each indoor unit may not output the rated capacity and one may differ from other, upon other installation/operation factors, it all units are turned on to run compressor simultaneously.
